Testo 526-1/-2 is a highly precise differential pressure-measuring instrument with an internal sensor. This has a measuring range from 0 to 2000 hPa. The instrument is optimally suited to pressure checks in sensitive industrial processes, and is available in 2 accuracy classes.

• Testo 526-1 accuracy 0.1 Precent of final value
• Testo 526-2 accuracy 0.05 Precent of final value

  The Testo 526-1/-2 additionally has two probe inputs for the connection of further probes for the measurement of pressure and temperature. A large selection of probes is available for this purpose. Especially for the purposes of tightness tests on containers, uninterrupted recording is possible via the test menu in Testo 526-1 and Testo 526-2. The subsequent processing of the measurement data via software or printout via the printer allows the documentation of the pressure test.

• Temp. compensated differential pressure sensor, 0 to 2000 hPa, integrated in instrument
• Measures leakage rate (pressure drop per time)
• Checks drop in pressure in containers, cables etc. via the built-in test menu
• 2 probe sockets to connect additional probes for measuring pressure, temperature, current/voltage


INSTRUCTION MANUAL [PDF]

TESTO-526-MANOMETER [PDF]

DECLARATION OF CONFORMITY [PDF]
